Windshield Washer Pump: Service and Repair
1.
Remove two retaining screws.
2.
Remove RH inner splash shield.
3.
Disconnect electrical connectors.
4.
Disconnect window washer hose and remove
windshield washer reservoir from vehicle.
NOTE: Windshield washer reservoir will drain with window washer hose disconnected.
5.
To install, reverse removal procedure. Fill
windshield washer reservoir with fluid.
