Fuse K

fuse K - protects the following circuits
^ Headlamps
^ Instrument Panel (I/P) Fuse Panel, Fuse 10
^ Fuse 5
^ Fuse 11
^ Fuse 17
^ Fuse 23
^ Fuse 29
^ Fuse 35
^ Fuse 41

Power Distribution:




Power Distribution:
