Information Bus: Specifications

Torque Specifications:

Item Specification

Heat shrink tube overlap 12.7 mm (0.5 inch)
Wire insulation removal length (twist side) 37.2 mm (1.5 inch)
Wire insulation removal length (receiving side) 19.5 mm (0.75 inch)
