Valve - Guide Inner Diameter
Valve - Guide Inner Diameter 1.
Measure the inner diameter of the
valve guides in 2 directions where indicated.
2.
If the
valve guide is not within specifications, ream the valve guide and install a valve with an oversize stem or remove the valve guide and install a new valve guide.
