Radiator Grille Opening Panel
Radiator Grille Opening PanelRemoval and Installation 1.
Remove the headlamp assemblies.
2.
Remove the 4 screws from the top of the radiator grille.
3.
Remove the radiator grille.
-
Position the radiator grille outward and release the retaining clips.
4.
Remove the radiator grille opening panel by pulling outward on the panel.
5.
To install, reverse the removal procedure.
