C302

Component ID: 49
Component : C302

Connector:
Name : C302
Color :
# of pins : 2

Pin Description Circuit
1 - 2235 20YL/DB
2 GROUND 2234 20BR/WT

Connector:
Name : C302
Color :
# of pins : 2

Pin Description Circuit
1 - 2229 20YL/DB
2 GROUND 2231 20BR/WT
