C321

Component ID: 68
Component : C321

Connector:
Name : C321
Color :
# of pins : 2

Pin Description Circuit
1 GROUND 2416 12BR
2 - 2415 12GY

Connector:
Name : C321
Color :
# of pins : 2

Pin Description Circuit
1 GROUND 460 12BR
2 - 461 12GY
