C323

Component ID: 70
Component : C323

Connector:
Name : C323
Color :
# of pins : 6

Pin Description Circuit
1 GROUND 479 10BR
2 - U43 10GY
2 - U432 14GY
3 - U359 14BK/VT
4 - 482 18BR/WT
5 GROUND 483 14BR
6 - 5135 18DB/BR

Connector:
Name : C323
Color :
# of pins : 6

Pin Description Circuit
1 GROUND 465 12BR
2 - 464 12GY
3 - 467 14BK/VT
4 - 468 18BR/WT
5 GROUND 466 14BR
5 - 5124 18BR
5 - U6127 14BR
6 - 5128 18DB/BR
