Rear Seat Lock Replacement
Rear Seat Lock ReplacementNOTE:
-
Put on gloves to protect your hands.
-
Take care not to tear the seams or damage the
seat covers.
1.
Remove the rear seat-back.
2.
Remove the seat-back cover/pad.
3.
Remove the bolts securing the rear seat lock (A).
