Throttle Position Sensor: Specifications
Excel, back out speed screws enough to close throttle valve. Connect DVOM between two lower horizontal blades of
TPS. Adjust screw on linkage to specified voltage.
4-cyl. Sonata, measure voltage along single upper (-) and lower left (+) terminals of
TPS.
V6 Sonata, measured between upper and lower right terminals of
TPS connector.
