Automatic Transmission/Transaxle: Application and ID: Specifications

SPECIFICATIONS

^ Severe use (marked *) is defined as:

1. Driving on rough road (bumpy road, gravel road, snowy road, unpaved road etc.)
2. Driving on mountain road, ascent/descent
3. Repetition of short distance driving
4. More than 50% operation in heavy city traffic during hot weather above 32°C (89.6°F)
5. Police car, Taxi, Commercial type operation or trailer towing, etc.
