86.77.07 Immobilisation - Electronic Control Unit (ECU)

86.77.07 Immobilisation - Electronic Control Unit (ECU)

Remove
1. Disconnect battery earth lead.
2. Remove fascia.

3. Remove 2 plastic nuts securing immobilisation ECU and disconnect multiplug. Remove immobilisation ECU.

Refit
1. Connect multiplug to immobilisation ECU.
2. Position ECU, fit and tighten 2 plastic nuts.
3. Fit fascia.
4. Connect battery earth lead.
5. Initiate using TestBook/T4.
