Parking Brake Warning Switch: Service and Repair
PARKING BRAKE WARNING INDICATOR SWITCH REMOVAL/INSTALLATION 1.
Remove the parking brake release handle bolt.
-
To install, tighten to 10 Nm {1.0 kgf-m, 89 in-lbf}.
2.
Disconnect the warning indicator switch electrical connector.
3.
Remove the bolt and warning indicator switch.
-
To install, tighten to 10 Nm {1.0 kgf-m, 89 in-lbf}.
4.
To install, reverse the removal procedure.
