Turn Signal Bulb: Service and Repair
SIDE LAMP/FRONT TURN SIGNAL LAMP BULB REMOVAL/INSTALLATIONRemoval/Installation 1.
Disconnect the front
turn signal lamp electrical connector.
2.
Rotate the front
turn signal lamp bulb holder approximately one-eighth turn counterclockwise and remove from the headlamp assembly.
-
Separate the bulb from the bulb holder.
3.
To install, reverse the removal procedure.
