Keyless Entry Module: Service and Repair




1st version up to 08/95





Sedan
Covering (1) on right-hand side of trunk
Remove, install.

Plastic nuts (arrows on N54)
Unscrew, screw on.

Control module (N54)
Remove, install.

Electric coupling
Disconnect, connect.


Coupe
Left rear seat cushion
Remove, install.

Plastic nuts
Unscrew, screw on.

Electric coupling
Disconnect, connect.

Control module (N54)
Remove, install.


NOTE: When replacing the control module or the transmitter key, always quote the locking mechanism number, since these two components are tuned to each other.
