Right Side of Engine
Right Side Engine Wiring Harness Assembly:
A CONNECTOR, IGNITION DISTRIBUTOR ELECTRICAL
B CONNECTOR, CANISTER PURGE SOLENOID VALVE ELECTRICAL
C CONNECTOR, INJECTOR ELECTRICAL
D CONNECTOR, MANIFOLD ABSOLUTE PRESSURE SENSOR ELECTRICAL
E CONNECTOR, GENERATOR ELECTRICAL
F CONNECTOR, A/C COMPRESSOR CLUTCH ELECTRICAL
G TUBE, VACUUM
H CONNECTOR, KNOCK SENSOR ELECTRICAL
J TERMINAL, ENGINE GROUND
K CONNECTOR, IDLE AIR CONTROL STEPPER MOTOR ELECTRICAL
L CONNECTOR, THROTTLE POSITION SENSOR ELECTRICAL
M CONNECTOR, OXYGEN SENSOR ELECTRICAL
9 BOLT/SCREW, ENGINE WIRING HARNESS CLAMP
10 HARNESS ASSEMBLY, ENGINE WIRING
11 NUT, ENGINE WIRING HARNESS GROUND
12 NUT, ENGINE WIRING HARNESS START LEAD
13 WASHER, ENGINE WIRING HARNESS START LEAD
14 LEAD, ENGINE WIRING HARNESS START
15 SENSOR ASSEMBLY, MANIFOLD ABSOLUTE PRESSURE
