Oil Pump Pipe And Screen Assembly Removal

OIL PUMP PIPE AND SCREEN ASSEMBLY REMOVAL





1. Remove the oil pump pipe and screen assembly bolts.
2. Remove the oil pump pipe and screen assembly.
3. Remove the oil pump pipe and screen assembly gasket.
4. Use solvent to clean the oil pump pipe and screen.
