Control Module Outputs
Legend ^
Wheel Speed, FR (430)
^
Wheel Speed, RL (540)
^
Return Pump (547)
^
ABS Warning Light On MIU (540)
^
Data Link (445)
^
Inlet Valve FL (547)
^
Outlet Valve FL (547)
^
Inlet Valve RR (547)
^
Outlet Valve FR (547)
^
Inlet Valve RL (547)
^
Outlet Valve RL (547)
^
Inlet Valve RR (547)
^
Outlet Valve RR (547)
