Control Module Outputs Part 1 of 2

^ Wheel Speed, Front Right (430) Front-Wheel Sensors

^ Wheel Speed, Rear Left (540) Rear-Wheel Sensors

^ Return Pump (382) Return Pump, TCS Function

^ ABS Warning Lamp on MIU (540) ABS Warning Lamp

^ Diagnostic Communications (445) Diagnostics Communication

^ TCS Off Indicator Lamp on MIU (540) Indicator Lamp TCS Off

^ TCS Lamp On MIU (540) Valve Block, ABS Function

^ Inlet Valve, FL (382) Valve Block, ABS Function

^ Outlet Valve FL (382) Valve Block, ABS Function

^ Inlet Valve, FR (382) Valve Block, ABS Function

^ Outlet Valve FR (382) Valve Block, ABS Function

^ Inlet Valve, RL (382) Valve Block, ABS Function

^ Outlet Valve RL (382) Valve Block, ABS Function

^ Inlet Valve, RR (382) Valve Block, ABS Function

^ Outlet Valve RR (382) Valve Block, ABS Function

^ Pressure Increase Valve 1 FL (382) Valve Block, TCS Function

^ Pressure Increase Valve 2 FR (382) Valve Block, TCS Function

^ Pressure Decrease Valve 1 FL (382) Valve Block, TCS Function

^ Pressure Decrease Valve 2 FL (382) Valve Block, TCS Function
