Solar Sensor: Service and Repair






Sunlight Photo Sensor

Special tools, testers and auxiliary items required

• Trim Removal Wedge (3409)

Removing

- Pry the Sunlight Photo Sensor (G107) or Sunlight Photo Sensor 2 (G134) - 1 - out of the instrument panel in the direction of the arrow with the Trim Removal Wedge (3409).





• On vehicles with Electronic Parking Assistance, disconnect additional connector.

- Disconnect the connector from the Sunlight Photo Sensor (G107) or Sunlight Photo Sensor 2 (G134).

Installing

- Install in reverse order of removal.
