Engine Coolant Temperature Sensor
Engine coolant temperature sensorReplace engine coolant temperature sensorRemoval -
Remove the lower cover and the tunnel side panel on the passenger side, see Dashboard
Dashboard -
Pull the floor mats to one side
-
Disconnect the wiring and the connectors
-
Carefully remove the sensor from the sleeve.
Installation -
In reverse order.
