ANTENNA FEEDER NO.1 INSPECTION
id092000812400
1. Disconnect the negative battery terminal. (See NEGATIVE BATTERY TERMINAL DISCONNECTION/CONNECTION.)
2. Remove the following parts:
- (1) A-pillar trim (See A-PILLAR TRIM REMOVAL/INSTALLATION.)
-
- (2) Glove compartment (See GLOVE COMPARTMENT REMOVAL/INSTALLATION.)
-
- (3) Dashboard under cover (See DASHBOARD UNDER COVER REMOVAL/INSTALLATION.)
-
- (4) Passenger-side lower panel (See LOWER PANEL REMOVAL/INSTALLATION.)
-
- (5) Upper column cover (See COLUMN COVER REMOVAL/INSTALLATION.)
-
- (6) Meter hood (See METER HOOD REMOVAL/INSTALLATION.)
-
- (7) Passenger-side decoration panel (See DECORATION PANEL REMOVAL/INSTALLATION.)
-
- (8) Audio panel (See AUDIO PANEL REMOVAL/INSTALLATION.)
-
- (9) Audio unit (See AUDIO UNIT REMOVAL/INSTALLATION.)
-
3. Disconnect antenna feeder No.2.
4. Verify that the continuity between antenna feeder No.1 terminals is as indicated in the table.
-
